The CLQ is an economical, fully luminous sealed flat panel designed for long-life and easy cleaning/wipe down maintenance. Selectable CCT and Wattage allow the color and lumen output to accommodate the various needs in a wide variety of applications. Back lit design fully illuminates the flat panel, eliminating hot spots. Medical, cleanroom, behavioral healthcare, food preparation/service, locker rooms, canopies, high-tech manufacturing, research centers, public spaces, restrooms, wet location, kitchens and much more. Easy to install, easy to clean, available in several sizes and vandal-resistant.
CONSTRUCTION: Aluminum extruded frame with steel back plate for high heat dissipation. Zero distance between the back cover and the frame to eliminate particle transfer. Low profile design is less than 2” deep.
OPTICAL SYSTEM: Lens is optimized to protect against yellowing and light degradation. Switchable CCT from 3500K, 4000K, and 5000K. Comes standard with an inner lens and a choice of outer lenses, including polycarbonate for areas of high-abuse and/or behavioral health. Other options are available, please inquire with factory. IK-10 with polycarbonate lens.
ELECTRICAL SYSTEM: >50,000 hour LEDs at L70 for reduced maintenance, switchable lumen technology allows for easy field-adjustable lighting output with three level switch located on back of panel. Operating temperatures: -10°C to 40°C (14°F to 104°F)
MOUNTING: The fixture can be surface, suspended, and recessed mounted. Integrated clips.
LISTINGS: NSF listed for food service/processing. BAA and UL listed for wet locations. Wet location is achieved ONLY when used in conjunction with ceilings that are designed to be resistant to water, moisture, dust, corrosion and other contaminants, especially NSF recommended ceiling configurations. Wet location LM79, LM80 and TM21 compliant. Tested in accordance with ISO 14644-1; suitable for ISO Class 3–9 positive pressure cleanrooms. Can be used in BSL 1-4 environments and for use in USP 797/800 environments. cETL and ETL listed.
WARRANTY: 5-Year Limited Warranty. Complete warranty and terms located at www.aelnow.com/warranty.
