ILLUMINATION
•Ultra-bright, energy efficient, long-life Red or Green LED.
•UV-stabilized ultra-clear acrylic edgelit panel providesconsistent, uniform illumination.
•Double face utilizes factory instalLED silver or white mylarbackground panel.
ELECTRICAL
•Dual 120/277 voltage.
•Charge rate/power “ON” LED indicator light and push-to-testswitch for mandated code compliance testing.
•4.8V long-life, maintenance-free, rechargeable NiCd battery.
•Internal solid-state transfer switch automatically connectsthe internal battery to LED board for minimum 90-minuteemergency illumination.
•Fully automatic solid-state, two-rate charger initiates batterycharging to recharge a discharged battery in 24 hours.
MOUNTING
•Compatible with drywall or drop ceiling mount installations.Bar hangers included.
HOUSING
•Premium-grade, extruded aluminum housing.
•Extruded Aluminum trim assembly is easily detachable frombelow, providing accessibility for service or maintenance,also available in black or white powder-coated finishes.
•Self-adhesive Chevron appliques and guide templateprovided for directional indication.
OPTIONS
•SDT: Self-diagnostic test feature performs monthly,biannually, and annually tests to ensure reliable operationand to meet electrical and life safety codes.
•2C: Dual-circuit option on the AC-only unit enables it to beconnected to two different (one acting as a back-up to theother) supplies at the same time.
•Custom: Signs available with requested ‘special’ wording.
•USA: Substantial transformation assembly in the U.S.complies with “AssembLED in the USA” under the BuyAmerican Act.
WARRANTY/LISTING
•Five year warranty on all electronics and housing. Batterypro-rated for five years.
•Meets UL924, NFPA 101 Life Safety Code, NEC, OSHA,Local and State Codes.
•UL listed for damp locations. (0°C – 50°C)
