PRODUCT SPECIFICATIONS

 ILLUMINATION

• Two fully adjustable 1.0W white LED lamp heads.

• High performance chrome-plated metal reflectors and plastic lens for optimal light distribution.

 ELECTRICAL

• Dual 120/277 voltage.

• Charge rate/power “ON” LED indicator light and push-to-test switch for mandated code compliance testing.

• LVD (low voltage disconnect) prevents battery from deep discharge.

• 6V maintenance-free, rechargeable sealed lead acid battery.

• Internal solid-state transfer switch automatically connects the internal battery to lamp heads for minimum 90-minute emergency illumination.

• Fully automatic solid-state, two rate charger initiates battery charging to recharge a discharged battery in 24 hours.

• Remote capacity of 10W standard.

 MOUNTING

• Bar hangers on the back box for recessed mount.

• Compatible with drop ceiling mount installations. Bar hangers included.

HOUSING

• Durable 20-gauge steel trim plate in white or black finish.

• Trim securely attached to housing with spring clips.

• Five year warranty on all electronics and housing. Battery pro rated for two years.

• Meets UL924, NFPA 101 Life Safety Code, NEC, OSHA, Local and State Codes.

• UL Listed for dry locations. (25°C)
