ILLUMINATION
• Two fully adjustable, 5.0 watt, MR-16 halogen lamp heads
standard.
• High performance MR16 halogen lamps with smooth
metallized reflector and glass lens for optimal
light distribution.

ELECTRICAL
• Dual 120/277 voltage.
• Charge rate/power “ON” LED indicator light and push-to-test
switch for mandated code compliance testing.
• LVD (low voltage disconnect) prevents battery from deep
discharge.
• 6V maintenance-free, rechargeable sealed lead acid battery.
• Internal solid-state transfer switch automatically connects
the internal battery to lamp heads for minimum 90-minute
emergency illumination.
• Fully automatic solid-state, two rate charger initiates battery
charging to recharge a discharged battery in 24 hours.

MOUNTING
• Universal knockout pattern on back plate for wall mount.
Snaps into place making internal electrical connections.
• Knockout for conduit applications.
HOUSING
• Injection-molded, engineering grade, 5VA flame retardant,
high-impact resistant, thermoplastic in white finish.

OPTIONS
• SDT: Self-diagnostic feature performs monthly, biannual,
and annual tests to ensure reliable operation and meet
electrical and life safety codes.
• HTR: Optional internal heater for cold temperature
(-9°C – 50°C) applications.
• LED: 3.3W high performance MR-16 base LED lamps for
increased center-to-center spacing.
• PLED: 5.0W high performance MR-16 base LED lamps
for premium center-to-center spacing.

WARRANTY / LISTING
• Five year warranty on all electronics and housing. Battery
pro rated for two years.
• Meets UL924, NFPA 101 Life Safety Code, NEC, OSHA,
Local and State Codes.
• UL Listed for damp locations (20°C – 40°C).
