ILLUMINATION
• Two, 6V/12V 12W adjustable bi-pin halogen lamp heads.
ELECTRICAL
• Dual 120V/277 voltage.
• Charge rate/power “ON” LED indicator light and push-to-test
switch for mandated code compliance testing.
• LVD (low voltage disconnect) prevents battery from deep
discharge.
• 6V sealed lead acid, maintenance-free, rechargeable
battery.
• Internal solid-state transfer switch automatically connects
the internal battery to lamp heads for minimum 120-minute
emergency illumination.
• Fully automatic solid-state, two rate charger initiates battery
charging to recharge a discharged battery in 24 hours.
• Remote capacity of 26W standard on 50W models.
MOUNTING
• Conveniently designed for use with T-bar grid ceilings.
• Holes provided on enclosure for wire-suspension mount.
HOUSING
• Durable 20-gauge steel construction.
• White or black finish.
WARRANTY / LISTING
• Five year warranty on all electronics and housing. Battery
pro rated for two years.
• UL Listed for damp locations (20°C – 50°C).
• Meets UL924, NFPA 101 Life Safety Code, NEC, OSHA,
Local and State Codes.
• Meets city of Chicago requirements.
