PRODUCT SPECIFICATIONS

 ILLUMINATION

• Two fixed optics 5.4 watt, glare-free lamp heads.

• Smooth thermoplastic reflector and plastic lens for optimal light distribution.

ELECTRICAL

• Dual 120/277 voltage.

• Charge rate/power “ON” LED indicator light and push-to-test switch for mandated code compliance testing.

• 6V maintenance-free, rechargeable Sealed lead acid battery.

• Internal solid-state transfer switch automatically connects the internal battery to lamp heads for minimum 90-minute emergency illumination.

• Fully automatic solid-state, two-rate charger initiates battery charging to recharge a discharged battery in 24 hours.

• LVD (Low voltage disconnect) prevents battery From deep discharge.

MOUNTING

• Surface mount via easy connect back plate, which fits most standard junction boxes and snaps into place making internal electrical connections.

• Suitable for wall or ceiling mount.

HOUSING

• Injection-molded, engineering-grade, 5VA flame retardant, high-impact resistant, thermoplastic in white or black finish.

WARRANTY/LISTING

• Five year warranty on all electronics and housing. Battery pro-rated for two years.

• Meets UL924, NFPA 101 Life Safety Code, NEC, OSHA, Local and State Codes.

• ETL listed for damp locations. (20°C – 50°C)
